Thinkware | Dash Cam U3000 Hardwire With LTE-Wifi Router
- 64GB MicroSD Card Included. (Upgradeable upto 256GB).
- Built-in GPS.
- U3000 64GB 1CH Hardwire With LTE-Wifi Router( Sim card is Not Included ).
- Built-in Radar for Front & Rear.
- Resolution: 4K UHD @30fps .
- Camera: 8.42 Megapixel, Sony Exmor R STARVIS.
- Viewing angle of 152° .
- Built-in Wi-Fi.
- Speed Camera Alerts.
- Camera: 8.42 Megapixel, Sony Exmor R STARVIS 2
- Thinkware Connected Service.
- Super Night Vision 4.0.
- Smart Parking Mode.
- New Advanced Driver Assisstance System.
- Optional Image Quality.
- Built-in Bluetooth.
- Sensor: 3-Axis Accelerometer G-Sensor (3D, ±3G).
- Multiple Recording Modes.
- Wide Dynamic Range.
- Format Free Technology.
- High Temperature Protection System.
- Sensor: 3-Axis Accelerometer G-Sensor (3D, ±3G).
- Parking Surveillance Mode.
- Built-in Motion & Impact Detection.
- Time Lapse Parking Mode.
- Multiple Recording Modes.
- Energy Saving Mode (2.0).
- Easy Wi-Fi device pairing with Thinkware Link App & Bluetooth.
- Format Free Technology.
- Power Input Power: DC 12/24V.
(Supplied, inc VAT)
Key Features
What's in the box
- Dash Cam.
- 12V Hardwire Power Cable.
- 12V Plug & Play Power Cable.
- 64GB MicroSD Card (1CH & 2CH)
- USB MicroSD Card Reader.
- Windshield Mount.
- Spare 3M Mounting Tape.
- CPL Filter
- Adhesive Cable Clips.
- Quick Start Guide.
- 1x Router RUT200
- 1x Wi-Fi Antenna (Swivel, RP-SMA male)
- 1x Quick Start Guide
- 1x Packaging Box
- 2x Adhesive Window Mount Antenna
- 1x Automotive Power Supply
- 1x Automotive to Bare Wire Adaptor
Dash cam
Router
Specifications
- Camera: 8.42 Megapixel, Sony Exmor R STARVIS 2.
- Resolution: 4K UHD (3840 X 2160} @30fps or 2K QHD (2560 X 1440} 60fps.
- Viewing Angle: 152° Diagonal
- Capacity: Micro SD Card 64GB / 128GB / 256GB.
- Sensor: 3-Axis Accelerometer G-Sensor (3D, ±3G).
- GPS: Built-in GPS.
- Built-in Bluetooth.
- WI-FI: Built-in Wi-Fi.
- Input Power : Power Input Power: DC 12/24V.
- Full Specifications Here.
4K UHD RESOLUTION
Equipped with the latest Sony Starvis2 IMX678 Image Sensors, you can record in crystal clear 4K 2160p UHD front and 2K 1440p QHD rear cam footage day or night at 30FPS. The 152° front and 128° rear wide-angle lens minimise blind spots to assure all events are recorded without fail.
Dynamic Recording at 60fps Select 2K QHD to choose from 30FPS or 60FPS A higher frame rate can deliver both smoother and sharper images
4K IMAGE QUALITY SETTINGS
The greater the amount of data on the image displayed through the screen, the better the image quality.
The U3000 provides a clearer image by adjusting the number of bits per second of recorded images stored
Standard Option – 24Mbps
High Option – 30Mbps
SUPER NIGHT VISION 4.0 WITH SONY STARVIS2
Sony STARVIS2 IMX678 will be applied to the Dashcam for the first ever Optimised night vision technology allows capturing images in low-light conditions both continuous & parking recording. Record the moment when maximising low light conditions by SHCG (Super High Control Gain)
PARKING SURVEILLANCE MODE
Parking Surveillance mode is automatically activated when you turn off the ignition. This captures footage when a motion or impact is detected so you have video evidence of mishaps like hit-and-runs while you’re away from your vehicle.
*Requires Hardwiring Cable or OBD II Power Cable and installation for Parking Surveillance mode
(professional installation recommended)
BUILT-IN THINKWARE RADAR
Front and Rear Detection with 2 Channel Models
Dual RADAR will be applied to the Dashcam for the first ever
Dual RADAR is built into the front and rear cameras and When a person or vehicle is detected in a low-power recording situation,
it immediately wakes up and starts recording motion.
Sensitivity can be set in 5 steps and can be detected from 1M minimum to 5M maximum
U3000 Dual RADAR Standby Times
MOTION DETECTION
Monitor and capture any motion around the vehicle for potential vandalism attempts.
IMPACT DETECTION
Monitor any impact to the vehicle while it is parked to catch any hit-and-run driver in the act while you are away.
TIME LAPSE PARKING MODE
Catch any potential bumps, scrapes and other incidents by recording footage from your vehicle when you are not nearby. Timelapse mode records at 2 frame per second (FPS) to reduce the size of the video file. This allows the dash cam to record longer than other dash cams whilst in parking mode.
ENERGY SAVING MODE 2.0
In Energy Saving mode, the dash cam goes on standby when entering Parking Surveillance mode and wakes up to record events triggered by impacts only.
When in use, the U3000 will go to sleep and soon after an impact has been detected by built-in G-sensor, the U3000 will wake up within a second and start recording for the next 20 seconds.
This allows the dash cam to conserve energy and increase up to 5 times the total duration of the dash cam’s Parking Surveillance mode.
U3000 Energy Saving 2.0 Standby Times
* Based on 4,500mAH battery (BAB-50) * Variables: Temperature, the efficiency of the battery by usage time, and change in current after a detection.
Strong Impact Notifications while Driving
Impact Notifications when Parked
Send Emergency Message
Remote Live View
Vehicle Status & Driving History
Captured Image of Most Recent Parking
BUILT-IN GPS ANTENNA
SAFETY CAMERA ALERTS
Get audio warnings from your cash cam when approaching a wide variety of road safety cameras*. Thinkware Dash Cams provides active alert for these 5 types of road safety cameras while still recording videos. *UK speed camera (Cyclops) database with regular free updates
RED LIGHT WARNING SYSTEM
SPEED CAMERA WARNING SYSTEM
RED LIGHT & SPEED CAMERA WARNING SYSTEM
AVERAGE SPEED WARNING SYSTEM
MOBILE ZONE WARNING SYSTEM
ADVANCED DRIVER ASSISTANCE SYSTEM (ADAS)
NEW REAR COLLISION WARNING SYSTEM(RCWS)
The vehicle enters the rear for more than 50 km, it will automatically alert the user and record.
FORWARD COLLISION WARNING SYSTEM (FCWS/ UFCWS)
Warns the driver of impending road hazards.
FRONT VEHICLE DEPARTURE WARNING(FVDW)
Informs the driver of the vehicle ahead starting to move.
LANE DEPARTURE WARNING SYSTEM (LDWS)
Detects if the vehicle is veering off the driving lane.
GPS MAPPING
With GPS, all Thinkware dash cams can record the vehicle’s driving speed and provide its precise location and routes identification on the map. The GPS Tracker helps you to accurately assess the details of the surrounding area. The PC/Mac viewer can then provide you with the vehicle speed and the time of a collision, and the severity of any impacts.
PC / MAC VIEWER
The intuitive and simple-to-use interface of Thinkware Dash Cam allows you an easy and convenient viewing of your recorded videos. Through PC or Mac viewer, you can playback and download recorded videos. You can also change the dash cam settings, format the memory card, or install updates with just a few clicks on the viewer.
MULTIPLE RECORDING MODES
CONTINUOUS RECORDING MODE
This mode is activated automatically when you start the engine. Recorded videos are saved in one-minute segments with an auto-looping mechanism.
INCIDENT RECORDING MODE
The Active Impact Monitoring System will automatically store the video data ten seconds prior to and after a collision registered by the 3-axis G-Sensor.
MANUAL RECORDING MODE
Similar to a video camera, you can use the Manual Recording Mode to capture events that occur in front of your vehicle whether or not it is in motion.
FAIL-SAFE RECORDING
In the event that the power gets disconnected after an accident, the fail-safe recording uses the Super Capacitor for backup power to ensure safe storage of any recording in progress.
EASY WI-FI DEVICE PAIRING WITH THINKWARE LINK APP & BLUETOOTH
Built-in Bluetooth allows hassle-free dash cam pairing with your compatible Android or iOS device via the Thinkware Link App. Once paired, replay your latest driving videos and manage your dash cam’s settings with the Thinkware Link App. CHECK RECORDED IMAGES AND UPDATE FIRMWARE USING SMARTPHONES Your smartphone and the U3000 can be connected via the exclusive application ‘THINKWARE DASH CAM Mobile Viewer for U3000’ with built-in Wi-Fi in the navigation. Check, download or delete recorded images, update firmware or update safe driving information on the application.
FORMAT FREE 2.0 TECHNOLOGY
Avoid corrupt memory cards and the slow process of having to reformat your SD Cards with the free flowing recording system. One of the most common issues with a Dash cam’s reliability is the SD card, these cards are continuously overwritten and often become corrupt if not formatted often. This normally means that you have to remove the SD card and put it into a computer to reformat it. Thinkware have overcome this vulnerability by making the dashcam pre-allocate the memory, avoiding the need to format the SD card on a regular basis and making the footage easily viewable on our Thinkware viewer software.
SMART PARKING MODE
When a high temperature occurs, it switches to Low power mode, and when it enters a stable Temperature, it actively changes to the existing Recording mode. * Provide optimised energy saving with THINKWARE`s external battery
REAR CAMERA
Designed to be mounted inside the vehicle on the rear window facing out. A 128° wide-angle lens captures all footage from behind the vehicle in 2K QHD detail. A great enhancement to parking mode. Includes Radar functionality for the rear of your vehicle.
This package is the perfect solution, connecting your U3000, Q1000 or Q850 to the internet allowing for all the advanced features of the units to be fully exploited.
The RUT200 is unlocked allowing you to use any network you wish. Alternatively, you can choose the Thinkware Connected SIM plan that is designed specifically for all the LTE needs of your chosen dashcam.
Dimensions
Setup Guide
Protect Your Battery
When ordering your router, you can choose either the iVolt version, which is intended to be installed with an iVolt external battery pack for its power supply or you can choose to install the router to the vehicle’s battery. This option is supplied with a voltage protector unit that monitors your vehicle’s power supply, much like the Thinkware dash cams, and will power the router down when it detects that the battery is getting low.
Data Plans
To use the Wi-Fi hotspot, you need a data plan, which can be either part of your existing mobile operators plan or a separate plan specifically for the car’s hotspot. These plans vary in data limits and pricing, so you can choose one that fits your needs.
Thinkware Connected offer a tailor-made LTE SIM plan, Specifically suited to the Thinkware dash cam user’s requirements, providing seamless network switching between Europe’s largest mobile phone networks for the best signal possible avoiding signal black spots.
With a data limit set to allow the average dash cam user to fully exploit the features such as remote live view, and parking impact notifications.
Enhanced Experience
The Wi-Fi router hotspot connects to the internet via a cellular network using the 2 windscreen mounted antenna. It then broadcasts a Wi-Fi signal inside the vehicle, allowing multiple devices like smartphones, tablets, laptops, and dash cams to connect to the internet simultaneously.
If you are using the Router for additional devices then you will need to look at a more extensive data plan.
Protect Your Battery
The hotspot covers the entire vehicle and is large enough to cover all types of vehicles from cars to buses, ensuring that all passengers can stay connected no matter where they are sitting.
The router can have up to 50 devices connected at any one time, allowing all passengers to benefit from the strong signal made possible via the windscreen-mounted antennas.
PAIR WITH THIS KIT
We recommend using these Thinkware Dash Cams with this Router Kit to get the full benefits of their Thinkware Connected abilities with no drop-off.
